HANDLING SKIPS
Drop bottom skip eco model – load 1000 kg
FAP-E
FAP-E
Capacities and dimensions
Glossary :
A : overall depth
B : interior depth
C : interior depth
I : interior width
D : overall height
D1 : interior height
E : maximum loading height
K : overall height (when emptying)
F : fork sleeves spacing
A : overall depth
B : interior depth
C : interior depth
I : interior width
D : overall height
D1 : interior height
E : maximum loading height
K : overall height (when emptying)
F : fork sleeves spacing
| CAPACITy litres |
load kg |
castors Ø |
A | B | C | I | D | K | weight kg |
PAINTED REF. |
| 500 | 1000 | – | 865 | 750 | 1335 | 1185 | 735 | 1405 | 90 | FEP05000 |
| 500 | 1000 | 125N | 865 | 750 | 1335 | 1185 | 800 | 1405 | 98 | FEP05120 |
| 800 | 1000 | – | 865 | 750 | 1335 | 1185 | 1125 | 1792 | 110 | FEP08000 |
| 800 | 1000 | 125N | 865 | 750 | 1335 | 1185 | 1185 | 1792 | 118 | FEP08120 |
| 1000 | 1000 | – | 865 | 750 | 1335 | 1185 | 1345 | 2012 | 125 | FEP10000 |
| 1000 | 1000 | 125N | 865 | 750 | 1335 | 1185 | 1405 | 2012 | 133 | FEP10120 |
| Dimensions in mm for basic model (for guidance only). | ||||||||||
Product features
- 3 capacities : 500, 800, 1000 litres
- Sheet metal bin 2 mm rib with reinforced corners
- Upper fork aperture 200 x 80 mm. 700 mm fork spacing (F)
- Caster-mounted model equipped with 2 fixed and 2 pivoting Ø 125 nylon casters (forward movement)
- One safety chain included
